TYPE-C线缆接线图表

最近更新

• TYPE-C接口形态



  USB Type C定义了新的接口形态。另外，为了兼容旧的接口以及一些特殊功能，它定义了不同形态的插座、插头、线缆。主要包括： 2种Type-C的插座全功能的Type-C插座，可以用于支持USB2.0、USB3.1、等特性的平台和设备。USB 2.0 Type-C插座，只可以用在支持USB2.0的平台和设备上...

  2022-11-14【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB3.1 TYPE-A插头线缆接线图



  USB TYPE-C和USB3.1 TYPE-A线缆接线图： USB信号定义：http://www.usbzh.com/article/detail-206.html USB接口大全：http://www.usbzh.com/article/detail-144.html TYPE-C信号定义：http://www.usbzh.com/article/detail-722.html This table assumes that shielded twisted pair is used for all SDP’s and there are drain wires. If coaxial wire ...

  2022-12-03【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB2.0 TYPE-A插头线缆接线图



  Pin A5 (CC) of the USB Type-C plug shall be connected to VBUS through a resistor Rp (56 kΩ ± 5%). See Section 4.5.3.2.2 and Table 4-24 for the functional description and value of Rp.Contacts B6 and B7 should not be present in the USB Type-C plug.All VBUS pins shall be connected together within the USB Type-C plug. Bypass capacitors are not requi...

  2022-11-06【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB3.1 TYPE-B插头线缆接线图



  Pin A5 (CC) of the USB Type-C plug shall be connected to GND through a resistor Rd (5.1 kΩ ± 20%). See Section 4.5.3.2.1 and Table 4-25 for the functional description and value of Rd.This table that shielded twisted pair is used for all SDP’s and there are drain wires. If coaxial wire construction is used, then no drain wires are present, and ...

  2022-12-14【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB2.0 TYPE-B插头线缆接线图



  Pin A5 (CC) of the USB Type-C plug shall be connected to GND through a resistor Rd (5.1 kΩ ± 20%). See Section 4.5.3.2.1 and Table 4-25 for the functional description and value of Rd.Contacts B6 and B7 should not be present in the USB Type-C plug.All VBUS pins shall be connected together within the USB Type-C plug. Bypass capacitors are not requ...

  2022-11-22【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB2.0 Mini-B插头线缆接线图



  Pin A5 of the USB Type-C plug shall be connected to GND through a resistor Rd (5.1 kΩ ± 20%). See Section 4.5.3.2.1 and Table 4-25 for the functional description and value of Rd.Contacts B6 and B7 should not be present in the USB Type-C plug.All VBUS pins shall be connected together within the USB Type-C plug. Bypass capacitors are not required ...

  2022-12-06【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB3.1 Micro-B插头线缆接线图



  Pin A5 (CC) of the USB Type-C plug shall be connected to GND through a resistor Rd (5.1 kΩ ± 20%). See Section 4.5.3.2.1 and Table 4-25 for the functional description and value of Rd.This table that shielded twisted pair is used for all SDP’s and there are drain wires. If coaxial wire construction is used, then no drain wires are present, and ...

  2022-12-22【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB2.0 Micro-B插头线缆接线图



  Pin A5 (CC) of the USB Type-C plug shall be connected to GND through a resistor Rd (5.1 kΩ ± 20%). See Section 4.5.3.2.1 and Table 4-25 for the functional description and value of Rd.Contacts B6 and B7 should not be present in the USB Type-C plug.All VBUS pins shall be connected together within the USB Type-C plug. Bypass capacitors are not requ...

  2022-12-01【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB3.1 TYPE-A插座适配器线缆接线图



  Pin A5 (CC) of the USB Type-C plug shall be connected to GND through a resistor Rd (5.1 kΩ ± 20%). See Section 4.5.3.2.1 and Table 4-25 for the functional description and value of Rd.This table that shielded twisted pair is used for all SDP’s and there are drain wires. If coaxial wire construction is used, then no drain wires are present, and ...

  2022-12-26【TYPE-C线缆接线图表】

  阅读全文

• USB TYPE-C和USB3.1 Micro-B插座适配器线缆接线图



  Pin A5 (CC) of the USB Type-C plug shall be connected to VBUS through a resistor Rp (56 kΩ ± 5%). See Section 4.5.3.2.2 and Table 4-24 for the functional description and value of Rp.Contacts B6 and B7 should not be present in the USB Type-C plug.All VBUS pins shall be connected together within the USB Type-C plug. Bypass capacitors are not requi...

  2022-11-06【TYPE-C线缆接线图表】

  阅读全文

• USB全功能TYPE-C线缆接线图



  This table that coaxial wire construction is used for all SDP’s and there are no drain wires. The shields of the coaxial wires are connected to the ground pins . If shielded twisted pair is used, then drain wires are needed and shall be connected to the GND pins.Pin B5 (VCONN) of the USB Type-C plug shall be used in electronically marked versions...

  2022-12-09【TYPE-C线缆接线图表】

  阅读全文

• USB2.0TYPE-C线缆接线图



  TYPE-C接口也可以只接USB2.0的信号。 Pin B5 (VCONN) of the USB Type-C plug shall be used in electronically marked versions of this cable. See Section 4.9.Contacts B6 and B7 should not be present in the USB Type-C plug.All VBUS pins shall be connected together within the USB Type-C plug. A bypass capacitor is not required for the VBUS pin i...

  2022-12-24【TYPE-C线缆接线图表】

  阅读全文
